FEATURES of IC STSPIN32F0601
- AEC-Q100 qualified
- Full ISO26262 compliant, ASIL-D systems ready
- VDH motor supply voltage range from 4.5V to 75.0V for working in single (12V systems), double (24V systems), and 48V battery applications
- 3.3V internal supply voltage generated from 5V on VDD pin
- Digital I/O compatible to 3.3V/5.0V logics
- 6 separate N-channel FET pre-drivers:
- Dedicated source connection to each FET
- The device can withstand -14V to +95V on motor connection pins
- 0% to 100% duty cycle operation support
- Dedicated PWM input pin for each gate driver
- 3 differential high accuracy current monitors for ground referred current measurements:
- ADC/DAC architecture
- SPI adjustable Gain Factor and Output Offset
- Built-in error calibration
- The device can withstand -14V to +6V on input sensing pins
- SPI readable current measurement
- 0 to 4.6V DAC output dynamic range
- 32-bit 10MHz SPI interface with 5-bit CRC and 1bit frame counter for internal setting, self-test, and full diagnostics
