Archana Press Brake Controller

Archana Press Brake Controller

Archana Press Brake Controller provides easy CNC design tool Machine adjustment and test bends are reduced to a minimum because of the quick and easy to use bend sequence determination tool.
The CNC program is generated with a one touch key stroke.  You are ready to make the first part since all axes positions are automatically computed and the bend sequence has already been simulated on the screen with the machine and tools in real scale.

In the production mode of the Digital Archana Press Brake Controller the operator can graphically simulate the bend process of the product guiding him during the press brake operation.
The basic machine control functions are Y1-Y2 and X axis, optionally a second back gauge axis can be used as R/Z or X2 axis. Also the crowning function is standard on board.

Features of Archana Press Brake Controller :

• 2D graphical programming
• 7 Segment LED Display
• Bend sequence determination
• Developed length calculation
• Crowning control
• USB peripheral interfacing
• Advanced Y-axis control algorithms for closed-loop as well as open-loop valves.

Electrical / interfacing

• Opto-isolated digital I/O
• Encoder inputs (single/diff.5V/12V)
• Integrated valve amplifier Y1, Y2
• RS232 port
•  USB port
•  Network interface (100Mb/10Mb)

Miscellaneous

•  Diagnostic program
• Sequencer functionality (PLC)
•  Error messaging system – On board analysis
• Operator selectable dialogue languages
• Help texts via online support
•  Safety PLC interfacing

Computed

•  Tooling safety zones
•  Press force
• Bend allowance
•  Crowning adjustment
• Bottoming force
• Angle correction database
•  Developed length
• Auto bumping calculation

Control

•  Servo / 2 speed AC control
• Unipolar / frequency inverter control
• Direct pressure valve control – Direct proportional valve Y1, Y2 control
• Up to 5 digital function outputs
• Tandem operation
